We are producing the woven filter cloth for quality and performance for over 8 years. The PP woven filter cloth are designed to provide optimal performance whether filtering intricate jobs with different liquids that have impurities, especially for Food grade works. PP woven filter cloth has good water-solubility, and widely used in plate and frame filter press. filtering milk, coke, coffee, drinking, wine and etc., easily and without effort.
Capacity: 2000 ㎡ a day.
FAW: 200-850gsm and other customized weight.
Weave: plain, twill, satin.
Any interests, please contact us freely.
Description
Models and Parameters (Accept customization)
| NAME | Breaking strength | Thread count | Thickness | Weight | Air Perm |
| (N/5*20cm) | (root/10cm) | (mm) | (g/m2) | L/m2.s | |
| 521 | 2608/2050 | 214.8/150.8 | 0.79 | 302.7 | 216.5 |
| 522 | 2104/1633 | 244/173 | 0.41 | 155 | 73.44 |
| 534 | 2501/1894 | 193.6/100.0 | 0.99 | 368.1 | 41.2 |
| 4212 | 2672/1342 | 236.4/123.2 | 1.34 | 389.4 | 85.6 |
| 700A | 3426.6/2819.4 | 204/106 | 0.7 | 350 | 117.9 |
| 700B | 4648.0/2866.6 | 188/114 | 0.59 | 280 | 254.2 |
| 700AB | 6865.4/416.7 | 378/235 | 1.15 | 580 | 82 |
| 750A(840A) | 4466/2905 | 168/131 | 0.85 | 330 | 42 |
| 750B(840B) | 5234/3489. | 256/141 | 0.99 | 420 | 76 |
| 750AB(840AB) | 6718/5421 | 333.8/204.4 | 1.36 | 489.9 | 24.5 |
| 840-1 | 5275/3948 | 252/146 | 0.9 | 440 | 45.5 |
| 840-2 | 5928/4086 | 283/142 | 1 | 490 | 40.7 |
| 840-3 | 6282/4858 | 311/134 | 1.1 | 520 | 27.2 |
| 858 | 4418/3618 | 251/124 | 0.88 | 380 | 240.7 |
| 4218 | 8568/5427 | 456/94 | 1.32 | 660 | 38.4 |
| 4135 | 6797/2508 | 346/83 | 1.02 | 510 | 19.12 |
| 4422 | 2643/1514 | 181/94 | 1.18 | 480 | 17.86 |
| 1000A | 5585.7/4089.2 | 204/102 | 0.85 | 435 | 9.83 |
| 1000B | 6636/1481 | 204/110 | 0.79 | 430 | 21.49 |
| 1500-1 | 56283701 | 251118 | 1.42 | 725 | 29.38 |
| 108B | 8721/4642 | 503/133 | 1.1 | 600 | 13.6 |
| 108C | 8367/4797 | 504/177 | 1.03 | 600 | 22.96 |
| 3927(120-16) | 4598/3154 | 156/106 | 0.9 | 524 | 18 |
There are 3 Types of PP Woven Filter Cloth
- Filament yarn: Long and smooth, good air permeability.
- Staple yarn: Short and rough, not good air permeability.
- Mono-filament
Features
- Materials used: polypropylene
- Working temperature: normal working temperature 88 ℃,110 ℃ peak working temperature.
- Air permeability
- Anti-corrosion
- Excellent acid resistance&good alkali resistance.
- Quality level: fine strength& good durability.
- High dimensional stability
- Good abrasion performance
- Wide range of filter rate
- Efficient fabric cleaning
Application
Liquid-solid separation and dust collection. Mainly used in precision chemical industry, Sugar-refinery, Pharmaceutical, alumina industry, etc., for equipment of frame filter press, belt filters, blend belt filter, disc filters, drum filters, centrifuge filters, etc.
Detailed information about how to choose a suitable filter media, please click.
