This machine is suitable for sealing tapes in all temperature of filter bag.Sealing tapes after sewing can reduce discharge standard effectively.The machine is easy to operate,temperature control stable,greatly improves production efficiency.
Description
Main Functions
- Suitable for sealing needle holes in filter bag body, head and bottom.
- Stepless speed regulation function.
- Automatic tape cutting function.
- Unique positioning device, precise taping position.
- Special heating device, the temperature can reach 700℃, the temperature fluctuates ±2℃, which is suitable for tape sealing of pure PTFE filter bag.
- Humanized operation panel, programmable parameter setting, simplifying the adjustment of the machine.
Basic Parameters
| Item | Specification |
|---|---|
| Power | 3.5kw |
| Rated Voltage | AC220V |
| Rated Frequency | 50-60HZ |
| Dimension | 1350×600×1530mm |
| PTFE Taping Speed | 0-15m/min |
| Compressed Air Pressure | 4-4.5kg/cm² |
